Air Filter-Regulator-Lubricator (FRLs)
STC offers a complete line of modular air-processing equipment. A-Series Filters, Regulators, and Lubricators (FRLs) are interchangeable with SMC-NAC Series FRLs. These FRL components are of modular design with joiner clamps that allow easy connection and disconnection of the FRL components for simple installation and maintenance. We carry a large inventory in our CA warehouse for quick shipping!
STC A Series FRLs Selection Guide (Click on a picture to get details) |
|||
| Filter- Regulator- Lubricator (AC) | Stacking Filter- Regulator- Lubricator (AC) | Filter (AF) | Lubricator (AL) |
 |
 |
 |
 |
| Regulator (AR) | Stacking Filter- Regulator (AW) | Relieving Shut-off/Lockout Valve (VHS) | FRL Mounting Hardware |
 |
 |
 |
 |
STC A Series FRLs (Interchangeable with SMC - NAC Series FRLs) |
||||
| Picture | Part No. | List Price | Description (*Includes Bracket & Gauge) | Symbol |
|
*Includes Bracket & Gauge |
AC1000-M5 | $56.65 | M5 Filter- Regulator- Lubricator* (3 SCFM) |  |
| AC2000-01 | $59.47 | 1/8" NPT Filter- Regulator- Lubricator* (18 SCFM) | ||
| AC2000-01D | $79.81 | 1/8" NPT Filter- Regulator- Lubricator* with Auto Drain (18 SCFM) | ||
| AC2000-01M | $71.82 | 1/8" NPT Filter- Regulator- Lubricator* Metal Bowl (18 SCFM) | ||
| AC2000-01DM | $88.11 | 1/8" NPT Filter- Regulator- Lubricator* with Auto Drain & Metal Bowl (18 SCFM) | ||
| AC2000-02 | $59.47 | 1/4" NPT Filter- Regulator- Lubricator* (18 SCFM) | ||
| AC2000-02D | $79.81 | 1/4" NPT Filter- Regulator- Lubricator* with Auto Drain (18 SCFM) | ||
| AC2000-02M | $70.12 | 1/4" NPT Filter- Regulator- Lubricator* Metal Bowl (18 SCFM) | ||
| AC2000-02DM | $90.43 | 1/4" NPT Filter- Regulator- Lubricator* with Auto Drain & Metal Bowl (18 SCFM) | ||
*Includes Bracket & Gauge |
AC3000-02 | $91.46 | 1/4" NPT Filter- Regulator- Lubricator* (70 SCFM) | |
| AC3000-02D | $118.06 | 1/4" NPT Filter- Regulator- Lubricator* with Auto Drain (70 SCFM) | ||
| AC3000-02M | $107.42 | 1/4" NPT Filter- Regulator- Lubricator* with Metal Bowl (70 SCFM) | ||
| AC3000-02DM | $134.03 | 1/4" NPT Filter- Regulator- Lubricator* with Auto Drain & Metal Bowl (70 SCFM) | ||
| AC3000-03 | $91.46 | 3/8" NPT Filter- Regulator- Lubricator* (70 SCFM) | ||
| AC3000-03D | $118.06 | 3/8" NPT Filter- Regulator- Lubricator* with Auto Drain (70 SCFM) | ||
| AC3000-03M | $107.42 | 3/8" NPT Filter- Regulator- Lubricator* with Metal Bowl (70 SCFM) | ||
| AC3000-03DM | $134.02 | 3/8" NPT Filter- Regulator- Lubricator* with Auto Drain & Metal Bowl (70 SCFM) | ||
| AC4000-03 | $123.35 | 3/8" NPT Filter- Regulator- Lubricator* (140 SCFM) | ||
| AC4000-03D | $156.52 | 3/8" NPT Filter- Regulator- Lubricator* with Auto Drain (140 SCFM) | ||
| AC4000-03M | $155.30 | 3/8" NPT Filter- Regulator- Lubricator* with Metal Bowl (140 SCFM) | ||
| AC4000-03DM | $173.93 | 3/8" NPT Filter- Regulator- Lubricator* with Auto Drain & Metal Bowl (140 SCFM) | ||
| AC4000-04 | $123.35 | 1/2" NPT Filter- Regulator- Lubricator* (140 SCFM) | ||
| AC4000-04D | $156.52 | 1/2" NPT Filter- Regulator- Lubricator* with Auto Drain (140 SCFM) | ||
| AC4000-04M | $155.30 | 1/2" NPT Filter- Regulator- Lubricator* with Metal Bowl (140 SCFM) | ||
| AC4000-04DC | $123.35 | 1/2" NPT Filter- Regulator- Lubricator* with Drain Cock (manual shut off valve) (140 SCFM) | ||
| AC4000-04DM | $173.93 | 1/2" NPT Filter- Regulator- Lubricator* with Auto Drain & Metal Bowl (140 SCFM) | ||
| AC4000-06 | $134.93 | 3/4" NPT Filter- Regulator- Lubricator* (160 SCFM) | ||
| AC4000-06D | $168.09 | 3/4" NPT Filter- Regulator- Lubricator* with Auto Drain (160 SCFM) | ||
| AC4000-06M | $166.86 | 3/4" NPT Filter- Regulator- Lubricator* with Metal Bowl (160 SCFM) | ||
| AC4000-06DM | $185.48 | 3/4" NPT Filter- Regulator- Lubricator* with Auto Drain & Metal Bowl (160 SCFM) | ||
| AC5000-10 | $170.06 | 1" NPT Filter- Regulator- Lubricator* (180 SCFM) | ||
| AC5000-10D | $213.97 | 1" NPT Filter- Regulator- Lubricator* with Auto Drain (180 SCFM) | ||
| AC5000-10M | $209.18 | 1" NPT Filter- Regulator- Lubricator* with Metal Bowl (180 SCFM) | ||
| AC5000-10DM | $248.99 | 1" NPT Filter- Regulator- Lubricator* with Auto Drain & Metal Bowl (180 SCFM) | ||
|
*Includes Bracket & Gauge |
AC1010-M5 | $50.66 | M5/10-32 Stacking Filter- Regulator- Lubricator* (3 SCFM) |  |
| AC2010-01 | $53.90 | 1/8" NPT Stacking Filter- Regulator- Lubricator* (18 SCFM) | ||
| AC2010-01D | $74.30 | 1/8" NPT Stacking Filter- Regulator- Lubricator* with Auto Drain (18 SCFM) | ||
| AC2010-01M | $64.54 | 1/8" NPT Stacking Filter- Regulator- Lubricator* with Metal Bowl (18 SCFM) | ||
| AC2010-01DM | $82.26 | 1/8" NPT Stacking Filter- Regulator- Lubricator* with Auto Drain & Metal Bowl (18 SCFM) | ||
| AC2010-02 | $53.90 | 1/4" NPT Stacking Filter- Regulator- Lubricator* (18 SCFM) | ||
| AC2010-02D | $74.30 | 1/4" NPT Stacking Filter- Regulator- Lubricator* with Auto Drain (18 SCFM) | ||
| AC2010-02M | $66.43 | 1/4" NPT Stacking Filter- Regulator- Lubricator* with Metal Bowl (18 SCFM) | ||
| AC2010-02DM | $82.28 | 1/4" NPT Stacking Filter- Regulator- Lubricator* with Auto Drain & Metal Bowl (18 SCFM) | ||
*Includes Bracket & Gauge |
AC3010-02 | $75.44 | 1/4" NPT Stacking Filter- Regulator- Lubricator* (60 SCFM) | |
| AC3010-02D | $102.07 | 1/4" NPT Stacking Filter- Regulator- Lubricator* with Auto Drain (60 SCFM) | ||
| AC3010-02M | $86.96 | 1/4" NPT Stacking Filter- Regulator- Lubricator* with Metal Bowl (60 SCFM) | ||
| AC3010-02DM | $109.78 | 1/4" NPT Stacking Filter- Regulator- Lubricator* with Auto Drain & Metal Bowl (60 SCFM) | ||
| AC3010-03 | $75.44 | 3/8" NPT Stacking Filter- Regulator- Lubricator* (60 SCFM) | ||
| AC3010-03D | $102.07 | 3/8" NPT Stacking Filter- Regulator- Lubricator* with Auto Drain (60 SCFM) | ||
| AC3010-03M | $91.42 | 3/8" NPT Stacking Filter- Regulator- Lubricator* with Metal Bowl (60 SCFM) | ||
| AC3010-03DM | $110.16 | 3/8" NPT Stacking Filter- Regulator- Lubricator* with Auto Drain & Metal Bowl (60 SCFM) | ||
| AC4010-03 | $108.98 | 3/8" NPT Stacking Filter- Regulator- Lubricator* (105 SCFM) | ||
| AC4010-03D | $142.16 | 3/8" NPT Stacking Filter- Regulator- Lubricator* with Auto Drain (105 SCFM) | ||
| AC4010-03M | $140.92 | 3/8" NPT Stacking Filter- Regulator- Lubricator* with Metal Bowl (105 SCFM) | ||
| AC4010-04 | $108.98 | 1/2" NPT Stacking Filter- Regulator- Lubricator* (105 SCFM) | ||
| AC4010-04D | $142.16 | 1/2" NPT Stacking Filter- Regulator- Lubricator* with Auto Drain (105 SCFM) | ||
| AC4010-04M | $140.92 | 1/2" NPT Stacking Filter- Regulator- Lubricator* with Metal Bowl (105 SCFM) | ||
| AC4010-04DM | $159.57 | 1/2" NPT Stacking Filter- Regulator- Lubricator* with Auto Drain & Metal Bowl (105 SCFM) | ||
| AC4010-06 | $124.56 | 3/4" NPT Stacking Filter- Regulator- Lubricator* (105 SCFM) | ||
| AC4010-06D | $157.73 | 3/4" NPT Stacking Filter- Regulator- Lubricator* with Auto Drain (105 SCFM) | ||
| AC4010-06M | $150.91 | 3/4" NPT Stacking Filter- Regulator- Lubricator* with Metal Bowl (105 SCFM) | ||
| AC4010-06DM | $158.00 | 3/4" NPT Stacking Filter- Regulator- Lubricator* with Auto Drain & Metal Bowl (105 SCFM) | ||
| AC5010-10 | $155.70 | 1" NPT Stacking Filter- Regulator- Lubricator* (140 SCFM) | ||
| AC5010-10D | $188.87 | 1" NPT Stacking Filter- Regulator- Lubricator* with Auto Drain (140 SCFM) | ||
| AC5010-10DM | $248.99 | 1" NPT Stacking Filter- Regulator- Lubricator* with Auto Drain & Metal Bowl (140 SCFM) | ||
|
|
AF1000-M5 | $14.36 | M5 Filter (4 SCFM) |  |
| AF2000-01 | $14.81 | 1/8" NPT Filter (26 SCFM) | ||
| AF2000-01D | $35.21 | 1/8" NPT Filter with Auto Drain (26 SCFM) | ||
| AF2000-01M | $22.03 | 1/8" NPT Filter with Metal Bowl (26 SCFM) | ||
| AF2000-01DM | $37.12 | 1/8" NPT Filter with Auto Drain & Metal Bowl (26 SCFM) | ||
| AF2000-02 | $14.81 | 1/4" NPT Filter (26 SCFM) | ||
| AF2000-02D | $35.21 | 1/4" NPT Filter with Auto Drain (26 SCFM) | ||
| AF2000-02M | $22.03 | 1/4" NPT Filter with Metal Bowl (26 SCFM) | ||
| AF2000-02DM | $38.73 | 1/4" NPT Filter Auto Drain & Metal Bowl (26 SCFM) | ||
 |
AF3000-02 | $22.34 | 1/4" NPT Filter (70 SCFM) | |
| AF3000-02D | $48.97 | 1/4" NPT Filter with Auto Drain (70 SCFM) | ||
| AF3000-02M | $30.32 | 1/4" NPT Filter with Metal Bowl (70 SCFM) | ||
| AF3000-02DM | $53.22 | 1/4" NPT Filter Auto Drain & Metal Bowl (70 SCFM) | ||
| AF3000-03 | $22.34 | 3/8" NPT Filter (70 SCFM) | ||
| AF3000-03D | $48.97 | 3/8" NPT Filter with Auto Drain (70 SCFM) | ||
| AF3000-03M | $30.32 | 3/8" NPT Filter with Metal Bowl (70 SCFM) | ||
| AF3000-03DM | $51.77 | 3/8" NPT Filter Auto Drain & Metal Bowl (70 SCFM) | ||
| AF4000-03 | $31.14 | 3/8" NPT Filter (140 SCFM) | ||
| AF4000-03D | $57.76 | 3/8" NPT Filter with Auto Drain (140 SCFM) | ||
| AF4000-03M | $39.12 | 3/8" NPT Filter with Metal Bowl (140 SCFM) | ||
| AF4000-03DM | $65.74 | 3/8" NPT Filter Auto Drain & Metal Bowl (140 SCFM) | ||
| AF4000-04 | $31.14 | 1/2" NPT Filter (140 SCFM) | ||
| AF4000-04D | $57.76 | 1/2" NPT Filter with Auto Drain (140 SCFM) | ||
| AF4000-04M | $39.12 | 1/2" NPT Filter with Metal Bowl (140 SCFM) | ||
| AF4000-04DM | $65.74 | 1/2" NPT Filter Auto Drain & Metal Bowl (140 SCFM) | ||
| AF4000-06 | $34.73 | 3/4" NPT Filter (210 SCFM) | ||
| AF4000-06D | $67.91 | 3/4" NPT Filter with Auto Drain (210 SCFM) | ||
| AF4000-06M | $42.71 | 3/4" NPT Filter with Metal Bowl (210 SCFM) | ||
| AF4000-06DM | $71.53 | 3/4" NPT Filter Auto Drain & Metal Bowl (210 SCFM) | ||
| AF5000-10 | $46.29 | 1" NPT Filter (245 SCFM) | ||
| AF5000-10D | $79.52 | 1" NPT Filter with Auto Drain (245 SCFM) | ||
| AF5000-10M | $54.29 | 1" NPT Filter with Metal Bowl (245 SCFM) | ||
| AF5000-10DM | $80.89 | 1" NPT Filter with Auto Drain & Metal Bowl (245 SCFM) | ||
|
*Includes Bracket & Gauge |
AR1000-M5 | $23.91 | M5/10-32 Regulator* (4 SCFM) |  |
| AR2000-01 | $24.73 | 1/8" NPT Regulator* (19 SCFM) | ||
| AR2000-02 | $24.73 | 1/4" NPT Regulator* (19 SCFM) | ||
| AR2500-02 | $35.32 | 1/4" NPT Regulator* (50 SCFM) | ||
| AR3000-02 | $38.31 | 1/4" NPT Regulator* (88 SCFM) | ||
| AR3000-03 | $38.31 | 3/8" NPT Regulator* (88 SCFM) | ||
| AR4000-03 | $51.09 | 3/8" NPT Regulator* (210 SCFM) | ||
| AR4000-04 | $51.09 | 1/2" NPT Regulator* (210 SCFM) | ||
| AR4000-06 | $59.07 | 3/4" NPT Regulator* (210 SCFM) | ||
| AR5000-06 | $63.90 | 3/4" NPT Regulator* (280 SCFM) | ||
| AR5000-10 | $63.90 | 1" NPT Regulator* (280 SCFM) | ||
 |
AL1000-M5 | $14.36 | M5 Lubricator (3 SCFM) |  |
| AL2000-01 | $14.81 | 1/8" NPT Lubricator (28 SCFM) | ||
| AL2000-01M | $21.67 | 1/8" NPT Lubricator with Metal Bowl (28 SCFM) | ||
| AL2000-02 | $14.81 | 1/4" NPT Lubricator (28 SCFM) | ||
| AL2000-02M | $21.67 | 1/4" NPT Lubricator with Metal Bowl (28 SCFM) | ||
|
|
AL3000-02 | $22.34 | 1/4" NPT Lubricator (60 SCFM) | |
| AL3000-02M | $30.32 | 1/4" NPT Lubricator with Metal Bowl (60 SCFM) | ||
| AL3000-03 | $22.34 | 3/8" NPT Lubricator (60 SCFM) | ||
| AL3000-03M | $30.32 | 3/8" NPT Lubricator with Metal Bowl (60 SCFM) | ||
| AL4000-03 | $31.14 | 3/8" NPT Lubricator (180 SCFM) | ||
| AL4000-03M | $47.10 | 3/8" NPT Lubricator with Metal Bowl (180 SCFM) | ||
| AL4000-04 | $31.14 | 1/2" NPT Lubricator (180 SCFM) | ||
| AL4000-04M | $47.10 | 1/2" NPT Lubricator with Metal Bowl (180 SCFM) | ||
| AL4000-06 | $34.73 | 3/4" NPT Lubricator (220 SCFM) | ||
| AL4000-06M | $52.53 | 3/4" NPT Lubricator with Metal Bowl (220 SCFM) | ||
| AL5000-10 | $49.10 | 1" NPT Lubricator (245 SCFM) | ||
| AL5000-10M | $65.08 | 1" NPT Lubricator with Metal Bowl (245 SCFM) | ||
|
*Includes Bracket & Gauge |
AW1000-M5 | $35.46 | M5 Filter- Regulator* (3 SCFM) |  |
| AW2000-01 | $35.52 | 1/8" NPT Filter- Regulator* (19 SCFM) | ||
| AW2000-01D | $54.15 | 1/8" NPT Filter- Regulator* with Auto Drain (19 SCFM) | ||
| AW2000-01M | $41.42 | 1/8" NPT Filter- Regulator* with Metal Bowl (19 SCFM) | ||
| AW2000-01DM | $59.47 | 1/8" NPT Filter- Regulator* Auto Drain & Metal Bowl (19 SCFM) | ||
| AW2000-02 | $35.52 | 1/4" NPT Filter- Regulator* (19 SCFM) | ||
| AW2000-02D | $54.15 | 1/4" NPT Filter- Regulator* with Auto Drain (19 SCFM) | ||
| AW2000-02M | $41.42 | 1/4" NPT Filter- Regulator* with Metal Bowl (19 SCFM) | ||
| AW2000-02DM | $59.47 | 1/4" NPT Filter- Regulator* Auto Drain & Metal Bowl (19 SCFM) | ||
 *Includes Bracket & Gauge |
AW3000-02 | $47.90 | 1/4" NPT Filter- Regulator* (70 SCFM) | |
| AW3000-02D | $74.52 | 1/4" NPT Filter- Regulator* with Auto Drain (70 SCFM) | ||
| AW3000-02M | $55.89 | 1/4" NPT Filter- Regulator* with Metal Bowl (70 SCFM) | ||
| AW3000-02DM | $82.50 | 1/4" NPT Filter- Regulator* Auto Drain & Metal Bowl (70 SCFM) | ||
| AW3000-03 | $47.90 | 3/8" NPT Filter- Regulator* (70 SCFM) | ||
| AW3000-03D | $74.52 | 3/8" NPT Filter- Regulator* with Auto Drain (70 SCFM) | ||
| AW3000-03M | $55.89 | 3/8" NPT Filter- Regulator* with Metal Bowl (70 SCFM) | ||
| AW3000-03DM | $82.50 | 3/8" NPT Filter- Regulator* Auto Drain & Metal Bowl (70 SCFM) | ||
| AW4000-03 | $71.86 | 3/8" NPT Filter- Regulator* (140 SCFM) | ||
| AW4000-03D | $105.03 | 3/8" NPT Filter- Regulator* with Auto Drain (140 SCFM) | ||
| AW4000-03M | $87.82 | 3/8" NPT Filter- Regulator* with Metal Bowl (140 SCFM) | ||
| AW4000-03DM | $120.97 | 3/8" NPT Filter- Regulator* Auto Drain & Metal Bowl (140 SCFM) | ||
| AW4000-04 | $71.86 | 1/2" NPT Filter- Regulator* (140 SCFM) | ||
| AW4000-04D | $105.03 | 1/2" NPT Filter- Regulator* with Auto Drain (140 SCFM) | ||
| AW4000-04M | $87.82 | 1/2" NPT Filter- Regulator* with Metal Bowl (140 SCFM) | ||
| AW4000-04DM | $120.97 | 1/2" NPT Filter- Regulator* Auto Drain & Metal Bowl (140 SCFM) | ||
| AW4000-06 | $83.84 | 3/4" NPT Filter- Regulator* (160 SCFM) | ||
| AW4000-06D | $117.01 | 3/4" NPT Filter- Regulator* with Auto Drain (160 SCFM) | ||
| AW5000-10 | $99.82 | 1" NPT Filter- Regulator* (195 SCFM) | ||
| AW5000-10D | $132.99 | 1" NPT Filter- Regulator* with Auto Drain (195 SCFM) | ||
| Picture | Part No. | List Price | Description (*Includes Bracket & Gauge) |
 |
Y20 | $4.64 | Spacer for AC2000 / AC2010 |
| Y30 | $7.75 | Spacer for AC3000 / AC3010 | |
| Y40 | $9.27 | Spacer for AC4000-04 / AC4010-04 | |
| Y50 | $9.27 | Spacer for AC4000-06 / AC4000-06 | |
| Y60 | $9.67 | Spacer for AC5000 / AC5010 | |
 |
Y20L | $5.05 | L-Type Spacer Bracket for AC2000 |
| Y30L | $7.75 | L-Type Spacer Bracket for AC3000 | |
| Y40L | $9.27 | L-Type Spacer Bracket for AC4000-04 | |
| Y50L | $9.27 | L-Type Spacer Bracket for AC4000-06 | |
| Y60L | $9.67 | L-Type Spacer Bracket for AC5000 | |
 |
Y20T | $5.42 | T-Type Spacer Bracket for AC2010 |
| Y30T | $9.27 | T-Type Spacer Bracket for AC3010 | |
| Y40T | $10.06 | T-Type Spacer Bracket for AC4010-04 | |
| Y50T | $10.84 | T-Type Spacer Bracket for AC4010-06 | |
| Y60T | $15.50 | T-Type Spacer Bracket for AC5010 | |
 |
Y21-N01 | $7.75 | Spacer with 1/8 NPT Port for AC2000 |
| Y21-N02 | $7.75 | Spacer with 1/4 NPT Port for AC2000 | |
| Y31-N01 | $11.61 | Spacer with 1/8 NPT Port for AC3000 | |
| Y31-N02 | $11.61 | Spacer with 1/4 NPT Port for AC3000 | |
| Y41-N02 | $13.92 | Spacer with 1/4 NPT Port for AC4000 | |
| Y41-N03 | $15.19 | Spacer with 3/8 NPT Port for AC4000 | |
| Y61-N03 | $19.34 | Spacer with 3/8 NPT Port for AC5000 | |
| Y61-N04 | $24.19 | Spacer with 1/2 NPT Port for AC5000 | |
 |
B110L | $4.64 | L-Bracket for AC1000 |
| B210L | $7.74 | L-Bracket for AC2000 | |
| B310L | $9.27 | L-Bracket for AC3000 | |
| B410L | $9.27 | L-Bracket for AC4000 | |
| B510L | $9.67 | L-Bracket for AC4000-06 | |
 |
B110T | $5.42 | T-Bracket for AC1010 |
| B210T | $8.51 | T-Bracket for AC2010 | |
| B310T | $10.06 | T-Bracket for AC3010 | |
| B410T | $10.83 | T-Bracket for AC4010 | |
| B510T | $15.48 | T-Bracket for AC4010-06 | |
 |
B120 | $2.33 | Bracket for AR/AW1000 |
| B220 | $2.52 | Bracket for AR/AW2000 | |
| B320 | $3.10 | Bracket for AR/AW3000 | |
| B420 | $3.87 | Bracket for AR/AW4000-5000 | |
|
|
B240 | $2.52 | Bracket for AF/AL2000 |
| B340 | $3.40 | Bracket for AF/AL3000 | |
| B440 | $3.87 | Bracket for AF/AL4000-04 | |
| B540 | $4.64 | Bracket for AF/AL4000-06 | |
| B640 | $6.20 | Bracket for AF/AL5000 | |
 |
GE 1-60 | $7.46 | 1" Dia. 1/16" 0-60 PSI back mount pressure gauge for 1000 series FRL |
| GE 1-160 | $7.46 | 1" Dia. 1/16" 0-160 PSI back mount pressure gauge for 1000 series FRL | |
| GE 1 1/2-30 | $7.46 | 1 1/2" Dia. 1/8" NPT 0-30 PSI back mount pressure gauge for 2000 series FRL | |
| GE 1 1/2-60 | $7.46 | 1 1/2" Dia. 1/8" NPT 0-60 PSI back mount pressure gauge for 2000 series FRL | |
| GE 1 1/2-160 | $7.46 | 1 1/2" Dia. 1/8" NPT 0-160 PSI back mount pressure gauge for 2000 series FRL | |
| GE 2-30 | $7.99 | 2" Dia. 1/4" NPT 0-30 PSI back mount pressure gauge for 3000-5000 series FRL | |
| GE 2-60 | $7.99 | 2" Dia. 1/4" NPT 0-60 PSI back mount pressure gauge for 3000-5000 series FRL | |
| GE 2-160 | $8.83 | 2" Dia. 1/4" NPT 0-160 PSI back mount pressure gauge for 3000-5000 series FRL | |
| GP 1 1/2-160 | $8.67 | 1 1/2" Dia. 1/8" NPT 0-160 PSI panel mount pressure gauge for 2000 series FRL | |
| GP 2-160 | $9.20 | 2" Dia. 1/4" NPT 0-160 PSI panel mount pressure gauge | |
| GA 1 1/2-60 | $12.77 | 1.5" Dia. 1/8" NPT 0-60 PSI SS housing back mount glycerin filled | |
| GA 1 1/2-160 | $12.77 | 1.5" Dia. 1/8" NPT 0-160 PSI SS housing back mount glycerin filled | |
|
|
VHS2000-01 | $26.92 | 1/8" NPT Relieving Shut-off / Lockout Valve for 2000-01 Series FRL |
| VHS2000-02 | $26.92 | 1/4" NPT Relieving Shut-off / Lockout Valve for 2000-02 Series FRL | |
| VHS3000-02 | $34.31 | 1/4" NPT Relieving Shut-off / Lockout Valve for 3000-02 Series FRL | |
| VHS3000-03 | $34.31 | 3/8" NPT Relieving Shut-off / Lockout Valve for 3000-03 Series FRL | |
| VHS4000-03 | $51.12 | 3/8" NPT Relieving Shut-off / Lockout Valve for 4000-03 Series FRL | |
| VHS4000-04 | $51.12 | 1/2" NPT Relieving Shut-off / Lockout Valve for 4000-04 Series FRL | |
| VHS5000-06 | $104.69 | 3/4" NPT Relieving Shut-off / Lockout Valve for 5000-06 Series FRL | |
| VHS5000-10 | $104.69 | 1" NPT Relieving Shut-off / Lockout Valve for 5000-10 Series FRL | |
STC AB Series FRLs |
|||||
| 1500-2000 Series | Part No. | Unit Price* | Unit Price (with Metal Bowl)* | Description | Flow Rate (SCFM) |
 |
AFC1500 | $40.13 | $49.44 | 1/8" NPT Stacked Filter- Regulator- Lubricator | 18 |
| AFC2000 | $40.13 | $49.44 | 1/4" NPT Stacked Filter- Regulator- Lubricator | 18 | |
 |
AFR1500 | $27.55 | $32.95 | 1/8" NPT Stacked Filter- Regulator | 18 |
| AFR2000 | $27.55 | $32.95 | 1/4" NPT Stacked Filter- Regulator | 18 | |
 |
AR1500 | $22.75 | - | 1/8" NPT Regulator | 18 |
| AR2000 | $22.75 | - | 1/4" NPT Regulator | 18 | |
| BR3000 | $27.55 | - | 3/8" NPT Regulator | 60 | |
| BR4000 | $27.55 | - | 1/2" NPT Regulator | 60 | |
 |
AF2000 | $13.17 | $18.49 | 1/4" NPT Filter | 18 |
 |
AL2000 | $13.79 | $20.43 | 1/4" NPT Lubricator | 18 |
A Series FRL Ordering Guide (e.g., AC1000-M5) |
||||
| Model | Body Size | Port Size | Options | Standard Features |
| AC = Filter- Regulator- Lubricator
AF = Filter AL = Lubricator AR = Regulator AW = Stacking Filter-Regulator |
1000 2000 3000 4000 5000 |
00 = 10-32 (M5)
01 = 1/8" NPT 02 = 1/4" NPT 03 = 3/8" NPT 04 = 1/2" NPT 06 = 3/4" NPT 10 = 1" NPT |
D = Automatic Drain
DC = Drain Cock (with manual shut off valve) M = Metal Bowl (with Sight Glass) P30 = 30PSI Regulating Range P60 = 60PSI Regulating Range F5 = 5 Micron Filter |
125PSI Regulating Range
Polycarbonate Bowl (3000-5000 Series with Steel Bowl Shield) Semi-Auto Differential Drain 25 Micron Sintered Brass Filter |
| AC = Stacking Filter- Regulator- Lubricator | 1010 2010 3010 4010 5010 |
00 = 10-32 (M5)
01 = 1/8" NPT 02 = 1/4" NPT 03 = 3/8" NPT 04 = 1/2" NPT 06 = 3/4" NPT 10 = 1" NPT |
D = Automatic Drain
DC = Drain Cock (with manual shut off valve) M = Metal Bowl (with Sight Glass) P30 = 30PSI Regulating Range P60 = 60PSI Regulating Range F5 = 5 Micron Filter |
125PSI Regulating Range
Polycarbonate Bowl (3000-5000 Series with Steel Bowl Shield) Semi-Auto Differential Drain 25 Micron Sintered Brass Filter |
Specifications |
|||||||||||
| Filter- Regulator- Lubricator (AC) | Stacking Filter- Regulator- Lubricator (AC) | Filter- Regulator (AW) | Regulator (AR) | Filters (AF) | Lubricators (AL) | ||||||
| Model | Air Flow Rate* SCFM (LPM) | Model | Air Flow Rate* SCFM (LPM) | Model | Air Flow Rate* SCFM (LPM) | Model | Air Flow Rate* SCFM (LPM) | Model | Air Flow Rate* SCFM (LPM) | Model | Air Flow Rate* SCFM (LPM) |
| AC 1000-00 | 3 (90) | AC 1010-00 | 3 (90) | AW 1000-00 | 3 (90) | AR 1000-00 | 4 (100) | AF 1000-00 | 4 (110) | AL 1000-00 | 3 (90) |
| AC 2000-XX | 18 (500) | AC 2010-XX | 18 (500) | AW 2000-XX | 19 (550) | AR 2000-XX | 19 (550) | AF 2000-XX | 26 (760) | AL 2000-XX | 28 (800) |
| AC 3000-XX | 70 (2000) | AC 3010-XX | 60 (1700) | AW 3000-XX | 70 (2000) | AR 3000-XX | 88 (2500) | AF 3000-XX | 70 (2000) | AL 3000-XX | 60 (1700) |
| AC 4000-XX | 140 (4000) | AC 4010-XX | 105 (3000) | AW 4000-XX | 140 (4000) | AR 4000-XX | 210 (6000) | AF 4000-XX | 140 (4000) | AL 4000-XX | 180 (5000) |
| AC 4000-06 | 160 (4500) | AC 4010-06 | 105 (3000) | AW 4000-06 | 160 (4500) | AR 4000-06 | 210 (6000) | AF 4000-06 | 210 (6000) | AL 4000-06 | 220 (6300) |
| AC 5000-XX | 180 (5000) | AC 5010-XX | 140 (4000) | AW 5000-XX | 195 (5500) | AR 5000-XX | 280 (8000) | AF 5000-XX | 245 (7000) | AL 5000-XX | 245 (7000) |
| *Measured with Supply Air Pressure @100PSI and Set Point Pressure @75PSI. | |||||||||||
Specifications |
|||||||||||||
| Model Series | Port Size | Port Size (Pressure Gauge) | Regulating Range | Max. Operating Pressure | Operating Temperature | Filtration | Bowl Material | Bowl Guard | Body Material | Construction/ Regulator |
Seals | Filter Drain | Service |
| 1000-00 | 10-32 (M5) | 1/16 Rc (PT) | 7 - 100PSI | 150PSI (9.9 kgf/cm^2) |
40 - 140°F (5 - 60°C) |
5 Micron Filter (Option); 25 Micron (Standard Sintered Brass Filter) |
Polycarbonate (Standard); Aluminum Metal (Option) |
N/A | Die-Cast ADC12 Aluminum | Relieving Type | NBR | Semi-Auto Differential Drain | For Air Only |
| 1010-00 | |||||||||||||
| 2000-XX | 1/8" or 1/4" NPT | 1/8" NPT | 7 - 125PSI (0.5 - 8.5 kgf/cm^2) | N/A | Semi-Auto Differntial Drain (Standard) Automatic Drain (Option) |
||||||||
| 2010-XX | |||||||||||||
| 3000-XX | 1/4" or 3/8" NPT | 1/8" NPT | Steel Bowl Guard | ||||||||||
| 3010-XX | |||||||||||||
| 4000-XX | 3/8" or 1/2" NPT | 1/4" NPT | |||||||||||
| 4010-XX | |||||||||||||
| 4000-06 | 3/4" NPT | 1/4" NPT | |||||||||||
| 4010-06 | |||||||||||||
| 5000-XX | 3/4" or 1" NPT | 1/4" NPT | |||||||||||
| 5010-XX | |||||||||||||
| These FRL components are of modular design with joiner clamps. The joiner clamps allow easy connection and disconnection of FRL components for simple installation and maintenance. | |||||||||||||
| Home | Terms of Use | Terms of Sale | Career | Contact Us | Click Here to Order |
|
Sizto Tech Corporation © 2001- All rights reserved. Last modified: May 10, 2016. Information contained herein may be changed without prior notification. |
|||||
